CP Olje/vann-separator CPP 360
For effektiv fjerning av oljerester i kondensatvann.
Type: CPP 360
Kapasitet: 21300 l/min
(Avhenger av et system med eller uten kjøletørke og separatorens omgivelses-temperatur)
Tilkobling: Inn: 3/4", Ut: 3/4"
Dimensjoner(LxBxH): 750 x 546 x 900mm
Vekt: 25kg
Tilgjengelige servicekit:
Servicekit A: Typisk brukt som det første filterskiftet etter installasjon, For å håndtere normal kondensat.
Servicekit B: For normal kondensat. Inneholder aktivt karbon-filter
Servicekit D: For kondensat med høyere oljeinnhold.
Removal of contaminants
in compressed air
condensate
At the end of the compression process, when the
air is cooled down, contaminated condensate is
generated.
• Once the condensate has been removed from the
compressed air, it still needs to be cleaned in order to
be in-line with local environmental legislations.
• Oil-water separators separate both substances (water
& oil), so the rinsed water can be discarded easily.
• The limited amount of oil has to be discharged in a
specialized disposal center
