Pistoldrill CP1117P60 Leveres uten chuck
Pistoldrill for industrielt bruk
Benefits
Improve your productivity thanks to high power & speed
Operator comfort thanks to exclusive ergonomic features
Drills for Industrial Production designed for intensive duty and high durability
Features
Industrial pistol drill without chuck
The best power to weight ratio with 1 hp (750 W) motor
Durable gearbox reduce maintenance cost and downtime
|
| Model | CP1117P60 (without chuck) | |
| Part number | 6151580200 | |
| Actual air consumption | 840 l/mn | 29.8 cfm |
| Air inlet thread size | 1/4 " | |
| Average air consumption | 280 l/mn | 597 cfm |
| Box dimensions | 170x250x75 mm | |
| Chuck capacity | 10 mm | 3/8 " |
| Collet / spindle size | | 3/8-24 " |
| Free speed | 6000 rpm | |
| Free speed air consumption | 16.5 l/s | 35.2 cfm |
| Length | 180 mm | 16.6 " |
| Min. hose size | 10 mm | 3/8 " |
| Net weight | 0.99 kg | 2.2 lb |
| Power | 750 W | 1 hp |
| Sound Power | 94 db(A) | |
| Sound pressure | 83 db(A) | |
| Stall torque | 3.4 Nm | 2 1/2 ft.lbs |
| Vibration | <2.5 m/s² | |
| Vibration ISO | ISO-28927-5 | |
| Vibration uncertainty (K) | - m/s² |
